FF Zoom

28-45MM T2 FF

28 712 NOK
Choose a mount to see availability
  • Advanced optical design and outstanding rendering performance
  • Professional-grade mechanical design and operability
  • Standardized Essentials: Gear position, Color Correction, Filter Size & Front Diameter
  • AF system with excellent tracking capability and near-silent operation

As the first AF-compatible Cine Lens series from Sigma,
the Sigma AF Cine Line brings innovation to the film production scene.

As the first AF-compatible Cine Lens series from Sigma,
the Sigma AF Cine Line brings innovation to the film production scene.

Building on the optical system of Sigma’s Art lenses, the AF Cine Line offers exceptional rendering performance, along with high-precision autofocus with excellent tracking capability, combined with the ergonomics required for professional cinema production.
This allows it to handle multiple shooting styles and on-set environments that were previously challenging with traditional still lenses or cine lenses.

The AF Cine Line, which embodies Sigma’s latest technology, expands the possibilities of visual expression and brings new possibilities to future film production.

Specifications
Features
Technology
Sample Images
Cine Lens Series FF Zoom
Focal lenght 28-45 mm
Aperture (T) T2 - T16
Number of diaphragm blades 11
Minimum Focusing Distance 0.3 m / 1'0 (*1)
Maximum magnification ratio 1:4
Front diameter 95 mm
Filter diameter 82 mm
LengthPagebuild

L-mount
Sony E-mount

151.3 mm  (*2)
153.3 mm  (*2)

WeightPagebuild

L-mount
Sony E-mount

1 200g
1 200g

Angle of View Full Frame 65.5 - 43.6° (*3)
Angle of View S35 47.9 - 30.9° (*4)
Focus Rotation 200°
Iris Rotation 57°
Lens Support Foot SF-91
EAN

L-mount
Sony E-mount

085126942984
085126942991

Specifications Info

* 1 Close focus distance is measured from the image plane
* 2 Front to mount flange
* 3 Horizontal angle of view for a full-frame cinema camera aperture (aspect ratio 1.5:1, dimensions 36 mm x 24 mm / 1.42" x 0.94")
* 4 Horizontal angle of view for an Super 35 cinema camera aperture (aspect ratio 1.33:1, dimensions 24.9 mm x 18.7 mm / 0.98″ x 0.74″)

Download Specification:

Advanced optical design and outstanding rendering performanceLenses compatible for full-frame

The optical systems of the Sigma 28-45mm T2 FF incorporate the designs of the highly acclaimed still lenses: the Sigma 28-45mm F1.8 DG DN | Art. Combining the experience gained through years of lens design, the latest development technology, and the advanced manufacturing techniques of Sigma's sole production base, the Aizu factory, these lenses deliver exceptional resolution and beautiful bokeh regardless of focal length or focus position, along with a sharp, clean look with minimal flare and ghosting.

Professional-grade mechanical design and operability

Inheriting the rendering performance and reliability of Sigma’s Art lenses, the AF Cine Line integrates cinema-style mechanics and operability, optimized for professional cinema production. It features a limited-rotation focus ring, industry-standard 0.8M pitch gears, and a clickless aperture ring to meet industry demands.

AF system with excellent tracking capability and near-silent operation

Equipped with a linear motor HLA (High-response Linear Actuator), the Sigma AF Cine Line captures intense movements in action scenes, rapid focus shifts in gimbal or handheld shooting, and unpredictable moments in documentaries without missing a split second, providing reliable support for filmmakers in various shooting situations.
